Expand Your Network Connectivity With This Rugged Unmanaged Network Switch - Fas IES5102
IES5102 | Startech®
Part Number: IES5102
Condition: New
Stock: 166
Real time availability
- Shipping Insurance
- Price Match Guarantee
- Terms of Service Guarantee
- Identity Theft Protection
Product Specifications
Expand Your Network Connectivity With This Rugged Unmanaged Network Switch - Fas IES5102
EXPAND YOUR NETWORK CONNECTIVITY WITH THIS RUGGED UNMANAGED NETWORK SWITCH - FAS
Manufacturer Part Number: IES5102
Startech Brochure PDF
User Manual PDF5Pt Industrial Ethernet Switch - Expand your network connectivity with this rugged unmanaged network switch - Fast 10/100Mbps Switch - DIN rail mountable with built-in bracket - Robust IP30-rated housing - Wide range 12-48V DC terminal block input - IEEE 802.3az Energy-Efficient Ethernet - Wider range of operating temperatures and ideal for industrial environments - Store-and-forward switching mechanism - Supports IEEE 802.3x flow control and back pressure.
MANUFACTURER NAME: Startech
MANUFACTURER PART NUMBER: IES5102
UPC EAN CODE: 065030859745
LANGUAGE: EN
MARKET:US
| General Information: | |
This compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments. It provides top performance in a wider range of operating temperatures than conventional network switches, making it ideal for factories and warehouses. | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | IES5102 |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | 5-Port Industrial Ethernet Switch - DIN Rail Mountable |
| Packaged Quantity | 1 |
| Product Type | Ethernet Switch |
| Product UPC | 065030859745 |
| Interfaces/Ports: | |
| Total Number of Network Ports | 5 |
| Network (RJ-45) | Yes |
| Modular | No |
| Stack Port | No |
| Port/Expansion Slot Details | 5 x Fast Ethernet Network |
| Media & Performance: | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10/100Base-TX |
| Network & Communication: | |
| Layer Supported | 2 |
| Management & Protocols: | |
| Manageable | No |
| Power Description: | |
| PoE (RJ-45) Port | No |
| Power Consumption | 2.12 W |
| Physical Characteristics: | |
| Product Color | Black |
| Product Material | Plastic |
| Form Factor | Rail-mountable |
| Height | 4.3" |
| Width | 1" |
| Length | 2.8" |
| Weight (Approximate) | 5.30 oz |
| Miscellaneous: | |
| What's in the box |
|
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty: | |
| Warranty | 2 Year |
Questions and Answers
Questions and Answers | Ask CompSource |
Shipping / Returns
Shipping
Ground =
$12.95
(EST. Arrival Date between
Tue.Sep.24 - Fri.Sep.27)
Two Day Air = $25.00
(EST. Arrival Date on Tue.Sep.24)
Standard One Day = $35.00
(EST. Arrival Date on Mon.Sep.23 after 3PM)
Priority = $45.00
(EST. arrival Date on Mon.Sep.23 in the AM)
U.S Mail Priority (AA,AE,AP only) = $30.00
FedEx International Economy (Canada only) = $85.00
Shipping dates are best estimates based on product location and may vary with holidays.
If product requires trucking, additional fees may apply.
* Some destinations are subject to Applicable State/Duty Taxes
Returns
CompSource realizes that every product may have different return guidelines. Please see the policy below regarding this item.
This Product Has Limited Exchange Privileges.
Limited returns within 30 days of purchase permitted on this product.
For support on this product, please contact Startech. 800-265-1844 www.startech.com
Startech Company's Information
Click Startech for all products
Local #: 800-265-1844
Toll Free #: 800-265-1844
Tech Support #: 519-455-4931
Site: www.startech.com
Accessories
Product Reviews
Overall Rating | Write a Review
|
|
Best Sellers
More Best Sellers
Rebates
More Rebates
Recently Viewed
About Startech
Did you know there are over 200 connector types and technologies used in IT solutions? IT professionals told us they need help making sense of it all, that's where we come in.
From the latest technology to legacy products, StarTech.com is your trusted advisor for connectivity.
StarTech.com makes it easy to identify, find, get and use the connectivity parts you need to enable business technology solutions. Here's how we do it:
Startech's story;
StarTech.com was founded in 1985 by Paul Seed and Ken Kalopsis. Paul and Ken met while attending the University of Western Ontario, in London, Ontario in the early eighties. Originally known as StarTech Computer Accessories, the company had very humble beginnings as a "Visa Card" founded operation, manufacturing products such as computer dust covers in the basement of a house.
The company has grown to become a global manufacturer of over 3000 products with operations in five continents but one thing hasn't changed: Startechs commitment to making our customers' jobs easier.
Here are just a few popular Startech categories:
CompSource is here to help with your Startech purchase. You can Chat with us or give our professionals a quick phone call (800)-413-7361, we can assist with the best Startech solution for your needs and budget.
Learn more about Switches & Bridges
Network Switch Buying Guide
Connect Multiple Devices to a Network and Route Data to Designated Devices
What is a network switch and what does it do?
A network switch connects devices to a local area network (LAN) and allows the devices to communicate over the network. For example, you can connect computers, printers and servers to the same network switch and route data between them. Unlike an Ethernet hub, which transmits the same data through every output, a network switch sends data only to the devices designated to receive it. This improves the efficiency and potential throughput of the network.
Are there different types of network switches?
There are two main types of network switches, unmanaged and managed. The essential difference is the capability to configure the operation of a managed switch to customize and optimize network traffic for specific applications.
Unmanaged Switches
- Offer plug-and-play functionality
- Switch operation cannot be modified
- CompSource offers desktop and rack-mount unmanaged switches
Managed Switches
- Provide the ability to manage, prioritize and monitor LAN traffic
- Offer one or more ways to modify switch operation
- CompSource offers smart managed switches that feature an RJ45 console port and command line interface (CLI)
Where do you place network switches?
Network switches are usually placed on a desk or table, mounted on a wall, or mounted in a rack. CompSource offers unmanaged desktop switches (with metal or plastic housing) and both unmanaged and managed rack-mount switches with metal housing and a built-in PDU (Gigabit Ethernet Switch PDU Combos).
What is a Gigabit Ethernet Switch PDU Combo?
CompSource offers an exclusive line of unmanaged and managed Gigabit Ethernet switches that have Power over Ethernet (PoE).
Factors to Consider
Does your application require a managed switch?
If your application involves controlling network traffic, you will need the features of a managed switch. The following are some examples of tasks that require a managed switch:
- Controlling access between departments within your LAN
- Running many bandwidth-intensive applications simultaneously
- Giving important data greater priority in your LAN
- Improving the performance of a busy network
- Implementing VoIP, wireless LANs or other advanced services
How many devices do you need to connect to your network?
Make sure you select a switch with enough Gigabit (10/100/1000 Mbps) Ethernet ports for the devices you want to connect to your network. If you think you'll add more devices in the future, choose a switch that will give your network room to grow.
Do you need to connect multiple network switches?
If you plan to connect multiple network switches, look for models with SFP uplink ports (also known as Mini-GBIC ports). SFP uplink ports are connection points for SFP (small form-factor pluggable) modules that allow the switch to uplink to other switches using optical fiber cabling.
Power over Ethernet (PoE) uses existing network cables to power connected devices, such as VoIP phones, wireless access points and surveillance cameras. If you need this functionality, look for a switch with Gigabit Ethernet ports that support PoE. Make sure the power per port (in watts) and the total power budget of the PoE ports meet the needs of your electronic devices.
